Description
Condition
Item is in “NEW AND UNUSED CONDITION” the original outer packaging will have some cosmetic damage and will have been opened to check contents. Sold with full manufacturer’s warranty. VAT invoice provided.
Specifications
Hardware Profile
- Sony Super HAD-II 1/4” CCD sensor
- 650 TVL resolution
- Minimum illumination: 0.1 lux (Color), 0.01 lux (B/W)
- Built-in Infrared-Cut Removable (ICR) filter module
- Electronic shutter: 1 to 1/10000 second
- S/N ratio > 50 dB (AGC off)
- 12x optical zoom
- Fixed length: 3.8 to 45.6 mm
- Aperture: F1.6 to F2.7
Field of View
- Horizontal: 52.8° to 4.49° / Vertical: 39.7° to 3.40°
PTZ Hardware Profile
- Pan travel: 360° endless
- Tilt travel: 10° to 170°
- Manual speed: 1° to 80°/second
- Presets: 256 points
- Preset Accuracy: 0.225°
- Preset Speed: 10° to 400°/second
- Sequence Paths: 8
- Auto Pan Paths: 4
- Cruise Paths: 8
- Pan and tilt speed proportional to zoom ratio
- Resume after power loss
- Home Functions: Preset, Sequence, Auto Pan, Cruise
- Auto Flip: Mechanical/Digital/Off
- Digital Slow Shutter
- Image Freeze
- Image Inverse
Image Features
- Configurable image size, quality, frame rate, and bit rate
- Time stamp and text overlays
- Configurable motion detection windows
- 3 configurable privacy mask zones
- Configurable white balance, shutter speed, brightness, saturation, contrast, and sharpness
Video Compression
- H.264/MPEG-4/MJPEG simultaneous format compression
- JPEG for still images
Video Resolution
- NTSC: 720 x 480, 352 x 240, 176 x 120 at up to 30 fps
- PAL: 720 x 576, 352 x 288, 176 x 144 at up to 25 fps
Audio Support
- G.726
External Device Interface
- 10/100 BASE-TX Ethernet port
- 8 alarm inputs
- 1 alarm output
- Audio input/output
- Video output
Network Protocols
- IPv4
- TCP/IP
- UDP
- ICMP
- DHCP Client
- NTP Client (D-Link)
- DNS Client
- DDNS Client (D-Link)
- SMTP Client
- FTP Client
- HTTP / HTTPS
- Samba Client
- PPPoE
- UPnP Port Forwarding
- RTP / RTSP/ RTCP
- IP filtering
- 3GPP
- IGMP
- ONVIF-Compliant
Security
- Administrator and user group protection
- Password authentication
- HTTP and RTSP digest encryption
System Requirements for Web Interface
- Operating System: Windows® 7, Windows Vista®, Windows® XP, Windows® 2000
- Browser: Internet Explorer, Mozilla Firefox, Netscape, Opera
Event Management
- Motion detection
- Event notification and upload snapshots/video clips via HTTP, SMTP or FTP
- Supports multiple HTTP, SMTP and FTP servers
- Multiple event notification
- Multiple recording methods for easy backup
Remote Management
- Configuration accessible via web browser
- Take snapshots/video clips and save to local hard drive or NAS via web browser
Mobile Support
- Windows 7®/Vista®/XP® system, Pocket PC, or mobile phone with 3GPP playback support
D-ViewCam™ System Requirements
- Operating System: Microsoft Windows 7/Vista/XP
- Web Browser: Internet Explorer 6 or higher
- Protocol: Standard TCP/IP
D-ViewCam™ Software Functions
- Remote management/control of up to 32 cameras
- Viewing of up to 32 cameras on one screen
- Supports all management functions provided in web interface
- Scheduled motion triggered or manual recording options
Power Input
- DC 12V/2A
Max. Power Consumption
- 14 watts
Environment
- Indoor Only
Operating Temperature
- 32 to 104° F (0° to 40° C)
Storage Temperature
- -4° to 158° F (-20° to 70° C)
Humidity
- 20% to 80% non-condensing
Weight
- 1.23lbs (560 grams)
Certifications
- CE (Class A)
- CE LVD (EN60965-1)
- FCC (Class A)
- ICES-003
- C-Tick
Dimensions
- Height: 8.07” (205mm)
- Diameter: 3.16” (131mm)
